How to change the VIN number in GM K43 electric Power steering control module using DPS

good jop i bought it and wating new  😀

6 hours ago, QUSAY OSMAN said:

HI TROY WE CAN DO THIS FOR ANY MODULE OR A CERTAIN MODULE

Only certain module that stores a Vin number like BCM, IPC, Brake ABS, Power steering. ECM can be done but I'm still working on a solution.

error

20 minutes ago, danial-jacob said:

error

Which car is it? Can you pm me the vin number?

This is brilliant. Recently I did some research on techline connect software, and I found  VINs could also be changed by the function of configuration&setup.

Could you share more info on how to change Vin on Tlc.

Up to a month ago i was able to change Ecm Vin by

Manually  type in  Vin, Highlight Vin, hit enter.

Was working like old sps, looks like they patched that as working no more.

3 hours ago, Carfixr1977 said:

Could you share more info on how to change Vin on Tlc.

Up to a month ago i was able to change Ecm Vin by

Manually  type in  Vin, Highlight Vin, hit enter.

Was working like old sps, looks like they patched that as working no more.

I don't know how to change vin in ECM using DPS.

Hi,i need help for reflash use hvac module so i try with sps2 but failed reprogramming so i have DPS 4.46.6000 but i not have hvac module address i test reading pcm,abs,bcm reading so i need dps file for reflash or change vin or unlock module for reflash,note if someone have all modules address for DPS,thanks.

Hi, can this work on 2013-2014 GMC Terrain and Chevrolet Equinox  electronic power  steering VIN replacement?

Can autel   maxiflash J2534 vci work with the DPS file?

19 minutes ago, Samuel Adu said:

Hi, can this work on 2013-2014 GMC Terrain and Chevrolet Equinox  electronic power  steering VIN replacement?

I don’t know as this file was created for insignia Buick Regal. If the files doesn’t work and you can provide the utility file for that module I can create a dps vin file of it.

On 4/25/2022 at 5:44 PM, Starmobile said:

Hi,i need help for reflash use hvac module so i try with sps2 but failed reprogramming so i have DPS 4.46.6000 but i not have hvac module address i test reading pcm,abs,bcm reading so i need dps file for reflash or change vin or unlock module for reflash,note if someone have all modules address for DPS,thanks.

HVAC vin change is now possible.

15 minutes ago, decode said:

HI Troy my car is malibu 2018 l need change VIN on EPS you think this file work for me the VEHICLE is from USA and lm in USA my question is because l have ioterminal and this tool no read flash no support 4 now thanks in advance

Hi, yes you can try that file if it doesn't work. Send me the EPS utility file and I will create a VIN change file that will work 100%

Hi, Troy I have paid and download the DPS how do I install and use it.

Am using autel maxiflash vci what interface do I need to connect the DPS.

I urgently need your support.

1 hour ago, Coby said:

Hi, Troy I have paid and download the DPS how do I install and use it.

You bought EPS Power Steering module VIN Number change Not DPS. The file you bought has the included instructions on how to use it with DPS to change the VIN in the EPS.

24 minutes ago, Coby said:

Am using autel maxiflash vci what interface do I need to connect the DPS.

I urgently need your support.

Any interface that works with GM GDS2 software will work with DPS.

Hi Troy, Do you know if this file would work for Equinox / Malibu power steering modules? I know a few people have already asked the same. Any idea it was successful? Thank you very much.

2 minutes ago, wpauto said:

Hi Troy, Do you know if this file would work for Equinox / Malibu power steering modules? I know a few people have already asked the same. Any idea it was successful? Thank you very much.

Hi, can you use DPS to find out if the EPS is a 2 or a 5-Byte seed and let me know? Use the photo below which shows how to identify 2 and 5-byte seed.

Here are some ready made EPS VIN change files for 5-Byte Equinox and Malibu below.

If the EPS is 2-Byte and you can provide the EPS calibration files, I can create the VIN change files for the 2-Byte seed EPS.

Thanks. I will check and get back to you. ECU ID for EPS is 31. Right?

1 minute ago, edkedk said:

Thanks. I will check and get back to you. ECU ID for EPS is 31. Right?

Yes, that's correct.

Here is the list of all the GM ECU IDs

3 hours ago, Troy said:



Yes, that's correct.

Here is the list of all the GM ECU IDs



It is 5 byte seed! Just tested on an Equinox. Would the VIN change file work for both Malibu and Equinox provided they are all 5-bytes? Thanks much!
