HMI theft lock, How to remove GM HMI theft lock with GM DPS, Plus more.

Welcome, one and all.

Feel free to ask any questions in the comments section for help.

Here, you will find information and files for upgrading your HMI v2 to the HMI v2.5 or replacing your HMI module with a used part.
Upgrading from HMI v2.0 to HMI v2.5 will enable Apple CarPlay, Android Auto, better SAT-NAV maps, video playback, and faster touch reaction from your touch screen.

Most of GM's electronic module car parts are security-locked to a specific car via the car's VIN number.

To install used car parts and have them functioning, you must first program your vehicle's VIN into the module.

When upgrading from the HMI v2.0 to the HMI v2.5, you must also upgrade the radio module. You can bypass the radio module upgrade by updating the firmware to v2.5 specs. (if you update the radio module firmware, you do not need to replace it)

The radio module upgrade firmware can be found below.

To get Apple Carplay to work, you will also need to replace your vehicle's double USB port with a single USB port.

See the photos below.

The items you will need for removing the theft lock from the HMI module:

A copy of GM DPS software, preferably V4.44.
My custom DPS HMI vin change file
A compatible GM diagnostic interface example: VXDIAG Nano, Drew tech mongoose GM2 pro, etc. (All diagnostic interfaces that work with GM's SPS will work with GM's DPS software.

GM DPS V4.44

This file will remove the theft lock from the HMI and radio module DPS VIN Relearn file.

This is for European cars/cars that use the SilverBox Radio module.

For USA cars/cars that use the satellite radio module.

GM HMI 2.5 Activate Video In Motion, SAT-NAV In Motion, Track-Pad, Rear Camera And Climate Control Using GM DPS

Check out this article, which demonstrates how to gain wireless Apple CarPlay and wireless Android Auto for GM vehicles that use the HMI 2.5 module.

The HMI module location and USB module you will need for Apple CarPlay.

Followers

User Feedback

80 Comments

Recommended Comments

+Alexpham

+Purchaser

May 13, 20215 yr

I will follow your threads to learn.

Thank you for sharing!

Quote

+KaDD

+Contributor

May 14, 20215 yr

Contributor

Subscribed.

Quote

Me Andme

Member

May 14, 20215 yr

This is so very interesting, the videos are a great step-by-step. It was by accident that I read your post at a forum and laughed so hard with your comebacks. Lets's say the awakening was the captured data in programming mode. I knew it was there until the "veil of darkness was lifted". Don't stop teaching.

Quote

Troy

Administrator

May 15, 20215 yr

GM Car Hacking Expert

29 minutes ago, Me Andme said:

This is so very interesting, the videos are a great step-by-step. It was by accident that I read your post at a forum and laughed so hard with your comebacks. Lets's say the awakening was the captured data in programming mode. I knew it was there until the "veil of darkness was lifted". Don't stop teaching.

Hi, I got alot of negative trolling on that forum from people who are unhappy that I publish the info publicly for free.

Due to them now not being able to charge expensive price to do it.

Yep, I will continue to teach others and learn from others.

Thanks.

Quote

+elmajestro

+Purchaser

May 17, 20215 yr

thank you too much for you help i am so happy to following you

please i need you make movies how upgrading your HMI v2 to the HMI v2.5

Quote

Troy

Administrator

May 17, 20215 yr

GM Car Hacking Expert

5 hours ago, elmajestro said:

thank you too much for you help i am so happy to following you

please i need you make movies how upgrading your HMI v2 to the HMI v2.5

You're welcome. Thanks.

Later when I'm able to fully crack the HMI I will make a full tutorial.

Quote

asav

Member

May 18, 20215 yr

Thank you! Great work.

Quote

ª-ashkan-

ªMemberª

May 20, 20215 yr

thanks for the info

Quote

+TunnerXP

+Contributor

May 22, 20215 yr

Contributor

thank you for your efforts.. keep it up

Quote

Troy

Administrator

May 22, 20215 yr

GM Car Hacking Expert

1 hour ago, TunnerXP said:

thank you for your efforts.. keep it up

Thanks Thank You GIF by Lumi

Quote

+Ernestas

+Contributor

May 23, 20215 yr

GM Car Hacking Expert

Contributor

Thanks to Troy and his efforts to share his knowledge, things like this can be done.(still need to sort annoying airbag light ? )

Quote

sergei petrov

Member

May 25, 20215 yr

GM Car Hacking Expert

Are there any examples of changing the configuration of cars? RPO cod

Quote

sergei petrov

Member

May 25, 20215 yr

GM Car Hacking Expert

8 minutes ago, Kade said:

In the first video it shows how to get your xml files, use it to add or remove RPO in the BuildRecord.xml.

Do I understand correctly that this way you can, for example, disable the TMPS system? or others?

Quote

+KaDD

+Contributor

May 25, 20215 yr

Contributor

1 minute ago, sergei petrov said:

Do I understand correctly that this way you can, for example, disable the TMPS system? or others?

I'm not sure if adding or removing the rpo code will activate or deactivate it.

You could try and see if it works.

Quote

sergei petrov

Member

May 25, 20215 yr

GM Car Hacking Expert

good. I'll try.

Quote

sergei petrov

Member

May 25, 20215 yr

GM Car Hacking Expert

Do you have any experience working with North American cars?

Quote

Troy

Administrator

May 26, 20215 yr

GM Car Hacking Expert

I only experiment with UK cars.

Quote

ªmuzikisme

ªMemberª

June 1, 20215 yr

Pretty cool Man! Nice to see the results of your hard work. Great job and keep it going!

Quote

Cadiblaster

Member

June 18, 20215 yr

Thanks Troy, this is an awesome post! Looking forward to messing around with my own replacement HMI/Radio modules to see what kind of fun I can have. ?

Quote

pronin272

Member

July 10, 20215 yr

It is very interesting to jointly make a guide to the purpose of each item in the menu for opening tabs of the instrument panel.
 Because information can only be obtained by brute force, trial and error

Quote

Cadiblaster

Member

July 17, 20215 yr

Anyone know how to force an HMI system software update using a USB thumb drive created from SPS? I'm attempting to switch a junkyard Chevy MyLink HMI to a Cadillac CUE HMI.

While the thumb drive is accessible to the HMI upon plugging it in to any of the USB ports, the upgrade is not acknowledged on my bench setup or in either of my Cadillacs. Gonna need more tinkering methinks...

Quote

Troy

Administrator

July 21, 20215 yr

GM Car Hacking Expert

You could try updating it in a car and not on the bench.

Quote

+dmytrofan

+Contributor

July 23, 20215 yr

Contributor

Will this work for the 2017 Buick Enclave from the USA?

Quote

Troy

Administrator

July 23, 20215 yr

GM Car Hacking Expert

4 minutes ago, dmytrofan said:

Will this work for the 2017 Buick Enclave from the USA?

If Enclave uses the same HMI 2.5, yes it should work.

Quote

ªbdiveley

ªMemberª

August 22, 20214 yr

I installed a used HMI 2.5 from a doner 2018 Camero. The CUE screen isn't displaying anything after the install. I was able to program the new radio and HMI in DPS according to Troy's instruction. Do I have a bad HMI?

I have a 2015 Cadillac SRX. Using VXDiag with a TDI subscription. 84278527 radio and 84364936 HMI 2.5

Any help would be appreciated.

Quote
