How to activate remote start and change VIN number in GM's instrument cluster BMC

In order to activate remote start on GM vehicles you need:

1. Find VIN car("new VIN"), which have remote start options (PRO code BTV).

2. Update firmware for BCM from SPS with "new VIN".

3. Change VIN in BCM from "new VIN" to your original VIN in order to odometer shows correct data. For this you need cheap CH341A EEPROM tool like this.

USB BIOS EEPROM SPI FLASH Programmer CH341A 24 25 series

The following video show you how to setup the chip reader and program the chip.

https://www.youtube.com/watch?v=5NYe21nFSDI

BCM block.

Chip location.

It would probably be best to first make a backup of the chip in case anything goes wrong. Then you can view the contents of the chip. In the software, the left side of the screen shows the actual program, which is displayed in Hexadecimal numbers. The right side shows a translation in plain text.

On the right side, look for a string of numbers that look like a VIN. It is usually only a few lines down from the top. It is always missing the first number of the VIN. Replace it with your VIN (minus the first number) by simply highlighting each letter on the right side and typing in your VIN. Then program back the chip and you’re done.


Followers

User Feedback

73 Comments

Recommended Comments

Scammer-SCAMMER T_Ivan

Scammer-SCAMMER

January 6, 20242 yr

On 08.08.2022 at 18:18, Sergey said:

Добрый день.
Никто не разобрался какие калибровки отвечают за автозапуск? Поменял 2. Система 9. Управление гидропередачей 20. Регулировка вентиляции и кондиционирования у меня машина перестала заводиться, хотя ошибок не было. Менял отдельно 9. Управление силовой передачей, но запуск не появился. Заменить все калибровки не получится, как я писал выше, автомобили-доноры не имеют точной конфигурации систем.

Good afternoon. Did you manage to remote start opel astra j?

Quote

+WSOpel

+Contributor

January 7, 20242 yr

Contributor

18 hours ago, T_Ivan said:

Good afternoon. Did you manage to remote start opel astra j?

YES

Quote

Scammer-SCAMMER T_Ivan

Scammer-SCAMMER

January 8, 20242 yr

22 hours ago, WSOpel said:

YES

Which blocks need to be updated? BCM?
Can you tell me what calibration needs to be added?

Quote

+karolputowski

+Contributor

February 1, 20242 yr

Contributor

On 4/21/2023 at 4:20 PM, WSOpel said:

I have test my Software and now i can do all Cars for 2010-2022 with remote Start ;D

@WSOpel Can you activate it in Opel Insignia 2015 A20DTH (EDC17)?

Quote

+uinbytes

+Contributor

August 25, 20242 yr

Contributor

@WSOpel

What needs to be edited and in which blocks?
W0LGT8GM5C1045901 the latest available calibrations have been installed.

Quote

+tobiasp

+Contributor

August 26, 20242 yr

Contributor

Hello, which tool need i to open the File from the ECU?

Quote

+GM-Enthusiast

+Contributor

August 27, 20242 yr

GM Car Hacking Expert

Contributor

On 8/26/2024 at 4:02 PM, tobiasp said:

Hello, which tool need i to open the File from the ECU?

HPTuner, Trasdata, Foxflash, EFILive, TunerCat, etc

Workshop Services

Car Hacking Services I Provide For General Motors Vehicles.

GM Remote Diagnosing and Troubleshooting
All GM Modules Programming
GM ECM/TCM Tuning
Auto Mechanic Workshop

Quote

+tobiasp

+Contributor

August 27, 20242 yr

Contributor

Hello, thanks a lot i will check it. Can i also other GM Calibrations open with this tools?

Quote

+uinbytes

+Contributor

October 5, 20241 yr

Contributor

Hey guys, what calibration flie (#1-20 bin) in the BCM is responsible for the remote start?

Quote

+tobiasp

+Contributor

October 31, 20241 yr

Contributor

Hi, What key with remote start works on a astra k or insignia b?

Quote

+BLKATSG

+Contributor

October 31, 20241 yr

GM Car Hacking Expert

Contributor

On 10/5/2024 at 5:04 PM, uinbytes said:

Hey guys, what calibration flie (#1-20 bin) in the BCM is responsible for the remote start?

It should be in Cal #5 I think.

Quote

+uinbytes

+Contributor

October 31, 20241 yr

Contributor

9 minutes ago, BLKATSG said:

It should be in Cal #5 I think.

Found in calibration #2

Post

Quote

+BLKATSG

+Contributor

October 31, 20241 yr

GM Car Hacking Expert

Contributor

8 minutes ago, uinbytes said:

Found in calibration #2

Post

Ah so just the timer is in #5 then. Or I'm thinking of the incorrect year BCM's

Quote

+tobiasp

+Contributor

October 31, 20241 yr

Contributor

Can you say what bytes must be changed?

Quote

Scammer-SCAMMER T_Ivan

Scammer-SCAMMER

November 15, 20241 yr

On 10/31/2024 at 10:04 PM, tobiasp said:

Can you say what bytes must be changed?

did you manage to find out?

Quote

+tobiasp

+Contributor

November 15, 20241 yr

Contributor

I test with original holden rhen remote start works. But i don't know waht i must changed in the engine ecu. Did you know it and dcan say it?

Quote

Scammer-SCAMMER T_Ivan

Scammer-SCAMMER

November 15, 20241 yr

3 minutes ago, tobiasp said:

I test with original holden rhen remote start works. But i don't know waht i must changed in the engine ecu. Did you know it and dcan say it?

you need to collect your DPS archive for the ECU and BCM and flash the car.

In the BCM it is necessary to change calibration 5, in the ECU I don’t know.

Quote

+tobiasp

+Contributor

November 15, 20241 yr

Contributor

Ah ok, that is right in BCM the File 5 only the ECM i don´t know what right is. With all files from the Holden Astra it works.

Quote

Scammer-SCAMMER T_Ivan

Scammer-SCAMMER

November 15, 20241 yr

10 minutes ago, tobiasp said:

Ah ok, that is right in BCM the File 5 only the ECM i don´t know what right is. With all files from the Holden Astra it works.

What's stopping you from leaving it as is?

Quote

+tobiasp

+Contributor

November 15, 20241 yr

Contributor

Haha no the adaptive cruise control not work it is not inside the holden file

Quote

Scammer-SCAMMER T_Ivan

Scammer-SCAMMER

November 19, 20241 yr

On 4/3/2023 at 10:55 PM, WSOpel said:

Hello Guys for Insignia i can activate Remote Start Finally. On Petrol you have to Change 1 DID

Hello.
When you say 1 DID, do you mean 1 calibration DPS or 1 DID in XML, for example DID0027?


1 DID for example DID0027?


Quote

Scammer-SCAMMER T_Ivan

Scammer-SCAMMER

November 23, 20241 yr

Hi all.
Help me out guys.
I found over 50 VIN numbers for Buick Enroce that came with BTV from the factory.
I checked all these numbers manually and wrote down the calibration numbers.

I made myself 12 different DPS archives, all of them successfully loaded into my car, but I still did not have a remote start menu in my radio.

The radio just now has a menu for turning on heated seats with remote start, but there is no remote start itself.

What am I doing wrong?

Quote

+tobiasp

+Contributor

November 23, 20241 yr

Contributor

Hi you need engine file and bcm file. Bcm number 5 and engine Nr. 1 or two. Search a car with same rpo and use this engine file

Quote
